PT8100 Service Manual
19
78 109-040393-R01 Chip resistor / 0402,39K±5%,ROHS 3 R64, R143, R278
79 109-040394-R01 Chip resistor / 0402,390K±5%,ROHS 3 R202, R220, R310
80 109-040433-R01 Chip resistor / 0402,43K±5%,ROHS 1 R163
81 109-040470-R01 Chip resistor / 0402,47R±5%,ROHS 1 R33
82 109-040471-R01 Chip resistor / 0402,470R±5%,ROHS 4 R100, R271, R290, R291
83 109-040472-R01 Chip resistor / 0402,4.7K±5%,ROHS 22
R5, R38, R39, R91, R128, R154, R158, R173, R176, R179, R180,
R191, R195, R197, R200, R203, R282, R283, R288, R289, R303,
R304
84 109-040473-R01 Chip resistor / 0402,47K±5%,ROHS 16
R89, R105, R123, R126, R127, R129, R141, R160, R238, R293,
R294, R300, R328, R331, R333, R337
85 109-040474-R01 Chip resistor / 0402,470K±5%,ROHS 6 R140, R165, R204, R250, R253, R305
86 109-040560-R01 Chip resistor / 0402,56R±5%,ROHS 2 R115, R135
87 109-040561-R01 Chip resistor / 0402,560R±5%,ROHS 2 R51, R55
88 109-040562-R01 Chip resistor / 0402,5.6K±5%,ROHS 7 R155, R178, R184, R193, R212, R241, R260
89 109-040563-R01 Chip resistor / 0402,56K±5%,ROHS 7 R97, R125, R149, R232, R258, R263, R275
90 109-040564-R01 Chip resistor / 0402,560K±5%,ROHS 2 R99, R243
91 109-040682-R01 Chip resistor / 0402,6.8K±5%,ROHS 6 R94, R95, R113, R114, R244, R317
92 109-040683-R01 Chip resistor / 0402,68K±5%,ROHS 3 R194, R264, R274
93 109-040821-R01 Chip resistor / 0402,820R±5%,ROHS 3 R76, R77, R255
94 109-040822-R01 Chip resistor / 0402,8.2K±5%,ROHS 2 R235, R242
95 109-040823-R01 Chip resistor / 0402,82K±5%,ROHS 3 R75, R88, R224
96 109-040913-R01 Chip resistor / 0402,91K±5%,ROHS 2 R190, R209
97 109-040914-R01 Chip resistor / 0402,910K±5%,ROHS 1 R221
98 109-060000-R01 Chip resistor / 0603,0R±5%,ROHS 5 C31, C176, D23, L52, L62
99 109-060100-R01 Chip resistor / 0603,10R±5%,ROHS 1 R8
100 109-060103-R01 Chip resistor / 0603,10K±5%,ROHS 1 R45
101 109-060121-R01 Chip resistor / 0603,120R±5%,ROHS 1 R4
102 109-060152-R02 Chip resistor / 0603,1.5K±1%,ROHS 1 R41
103 109-060220-R01 Chip resistor / 0603,22R±5%,ROHS 1 R30
104 109-060221-R01 Chip resistor / 0603,220R±5%,ROHS 1 L8
105 109-060222-R01 Chip resistor / 0603,2.2K±5%,ROHS 2 R18, R19
106 109-060271-R01 Chip resistor / 0603,270R±5%,ROHS 1 R44
107 109-060274-R01 Chip resistor / 0603,270K±5%,ROHS 1 R36
108 109-060332-R01 Chip resistor / 0603,3.3K±5%,ROHS 1 R32
109 109-060470-R01 Chip resistor / 0603,47R±5%,ROHS 2 R29, R34
110 109-060473-R01 Chip resistor / 0603,47K±5%,ROHS 2 R182, R206
111 109-060561-R01 Chip resistor / 0603,560R±5%,ROHS 2 R22, R23
112 109-060681-R01 Chip resistor / 0603,680R±5%,ROHS 1 R58
113 109-070000-R01 Chip resistor / 0805,0R±5%,ROHS 1 L54
114 109-070220-R01 Chip resistor / 0805,22R±5%,ROHS 1 L30
115 109-070470-R01 Chip resistor / 0805,47R±5%,ROHS 1 L31
116 109-100221-R01 Chip resistor / 1206,220R±5%,ROHS 2 R46, R47
117 110-110503-R01 Chip trimming resistor / EVM2NSX80B54,50K±25%,ROHS 1 VR2
118 111-010000-R01 plug-in piezoresistance / 10D220，ROHS 1 R281
119 111-030000-R07 Chip Resettable Fuse / 1206L150PR,1206,1.5A/6V,ROHS 1 F1
120 111-030000-R09 plug-in glass tube fuse / 313010,32V,10A,ROHS 4
121 112-043100-R01 Chip capacitor / 0402,10P±0.5P,50V,C0G,ROHS 6 C7, C16, C80, C138, C139, C307
122 112-043101-R01 Chip capacitor / 0402,100P±5%,50V,C0G,ROHS 28
C27, C28, C97, C103, C105, C108, C112, C114, C125, C335,
C336, C349, C350, C351, C352, C353, C354, C356, C359, C360,
C361, C362, C363, C364, C369, C382, C383, C384
123 112-043102-R01 Chip capacitor / 0402,1000P±10%,50V,X7R,ROHS 38
C82, C98, C19, C21, C36, C37, C49, C57, C58, C59, C68, C87,
C89, C90, C91, C92, C95, C99, C167, C170, C171, C188, C189,
C196, C206, C214, C220, C223, C231, C266, C311, C321, C370,
C371, C372, C373, C413, C416
124 112-043103-R01 Chip capacitor / 0402,0.01uF±10%,50V,X7R,ROHS 15
C33, C51, C55, C81, C110, C115, C121, C133, C145, C153, C242,
C284, C330, C333, C385
125 112-043104-R02 Chip capacitor / 0402,0.1uF±10%,16V,X7R,ROHS 41
C17, C23, C24, C83, C102, C144, C172, C173, C183, C184, C186,
C187, C204, C209, C210, C211, C213, C230, C235, C253, C259,
C260, C261, C264, C268, C270, C271, C272, C275, C295, C300,
C308, C312, C319, C325, C329, C334, C337, C338, C394, R296
126 112-043105-R01 Chip capacitor / 0402,1uF±10%,6.3V,X5R,ROHS 11
C56, C120, C254, C280, C298, C303, C304, C323, C367, C378,
C414
127 112-043123-R01 Chip capacitor / 0402,0.012uF±10%,25V,X7R,ROHS 3 C252, C292, C386
128 112-043150-R01 Chip capacitor / 0402,15P±5%,50V,C0G,ROHS 5 C13, C53, C118, C168, C190
129 112-043151-R01 Chip capacitor / 0402,150P±5%,50V,C0G,ROHS 1 C195
130 112-043153-R01 Chip capacitor / 0402,0.015uF±10%,50V,X7R,ROHS 6 C249, C258, C263, C273, C387, C389
131 112-043181-R01 Chip capacitor / 0402,180P±10%,50V,X7R,ROHS 2 C2, C106
132 112-043182-R01 Chip capacitor / 0402,1800P±10%,50V,X7R,ROHS 3 C154, C158, C217
