PT8100 Service Manual
20
133 112-043183-R01 Chip capacitor / 0402,0.018uF±10%,25V,X7R,ROHS 4 C257, C276, C390, C391
134 112-0431R5-R01 Chip capacitor / 0402,1.5P±0.25P,50V,C0G,ROHS 2 C69, C70
135 112-043200-R01 Chip capacitor / 0402,20P±5%,50V,C0G,ROHS 2 C281, C296
136 112-043221-R01 Chip capacitor / 0402,220P±5%,50V,C0G,ROHS 1 C282
137 112-043222-R01 Chip capacitor / 0402,2200P±10%,50V,X7R,ROHS 1 C248
138 112-043223-R01 Chip capacitor / 0402,0.022uF±10%,25V,X7R,ROHS 5 C238, C239, C322, C355, C365
139 112-043270-R01 Chip capacitor / 0402,27P±5%,50V,C0G,ROHS 3 C194, C197, C198
140 112-043273-R01 Chip capacitor / 0402,0.027uF±10%,50V,X7R,ROHS 1 C396
141 112-0432R0-R01 Chip capacitor / 0402,2P±0.25P,50V,C0G,ROHS 2 C104, C201
142 112-043330-R01 Chip capacitor / 0402,33P±5%,50V,C0G,ROHS 5 C6, C93, C130, C147, C232
143 112-043331-R01 Chip capacitor / 0402,330P±10%,50V,X7R,ROHS 1 C140
144 112-043332-R01 Chip capacitor / 0402,3300P±10%,50V,X7R,ROHS 1 C297
145 112-043333-R01 Chip capacitor / 0402,0.033uF±10%,16V,X7R,ROHS 1 C243
146 112-043360-R01 Chip capacitor / 0402,36P±5%,50V,C0G,ROHS 1 C205
147 112-043390-R01 Chip capacitor / 0402,39P±5%,50V,C0G,ROHS 2 C225, C229
148 112-043392-R01 Chip capacitor / 0402,3900P±10%,50V,X7R,ROHS 8 C256, C301, C314, C377, C399, C400, C401, C402
149 112-043393-R01 Chip capacitor / 0402,0.039uF±10%,10V,X7R,ROHS 4 C156, C250, C251, C288
150 112-0433R0-R01 Chip capacitor / 0402,3P±0.25P,50V,C0G,ROHS 3 C124, C177, C291
151 112-043470-R01 Chip capacitor / 0402,47P±5%,50V,C0G,ROHS 2 C129, C255
152 112-043471-R01 Chip capacitor / 0402,470P±10%,50V,X7R,ROHS 55
C3, C9, C11, C12, C20, C38, C47, C52, C54, C71, C76, C88,
C116, C119, C123, C128, C136, C142, C143, C148, C151, C157,
C160, C169, C174, C178, C182, C207, C212, C215, C218, C221,
C222, C247, C274, C279, C283, C285, C293, C302, C305, C310,
C317, C326, C328, C332, C339, C340, C342, C343, C347, C348,
C392, C395, C405
153 112-043472-R01 Chip capacitor / 0402,4700P±10%,25V,X7R,ROHS 1 C262
154 112-043473-R01 Chip capacitor / 0402,0.047uF±10%,16V,X7R,ROHS 3 C287, C294, C306
155 112-043474-R01 Chip capacitor / 0402,0.47uF±10%,10V,X5R,ROHS 1 C267
156 112-0434R0-R01 Chip capacitor / 0402,4P±0.25P,50V,C0G,ROHS 4 C35, C162, C163, C208
157 112-0435R0-R01 Chip capacitor / 0402,5P±0.25P,50V,C0G,ROHS 1 C200
158 112-043681-R01 Chip capacitor / 0402,680P±10%,16V,X7R,ROHS 1 C132
159 112-043682-R01 Chip capacitor / 0402,6800P±10%,16V,X7R,ROHS 1 C299
160 112-043683-R02 Chip capacitor / 0402,0.068uF±10%,10V,X7R,ROHS 7 C236, C240, C357, C358，C244, C245, C320
161 112-0436R0-R01 Chip capacitor / 0402,6P±0.5P,50V,C0G,ROHS 7 C72, C73, C126, C161, C164, C166, C175
162 112-0437R0-R01 Chip capacitor / 0402,7P±0.5P,50V,C0G,ROHS 1 C107
163 112-043820-R01 Chip capacitor / 0402,82P±5%,50V,C0G,ROHS 1 C234
164 112-043821-R01 Chip capacitor / 0402,820P±10%,16V,X7R,ROHS 3 C406, C409, C412
165 112-0438R0-R01 Chip capacitor / 0402,8P±0.5P,50V,C0G,ROHS 2 C165, C192
166 112-0439R0-R01 Chip capacitor / 0402,9P±0.5P,50V,C0G,ROHS 1 C100
167 112-043R50-R01 Chip capacitor / 0402,0.5P±0.1P,50V,C0G,ROHS 5 C48, C60, C61, C65, C127
168 112-063101-R01 Chip capacitor / 0603,100P±5%,50V,C0G,ROHS 1 C18
169 112-063102-R01 Chip capacitor / 0603,1000P±10%,50V,X7R,ROHS 13
C22, C25, C26, C64, C67, C77, C78, C79, C84, C85, C86, C101,
R7
170 112-063104-R01 Chip capacitor / 0603,0.1uF±10%,50V,X7R,ROHS 1 C96
171 112-063150-R01 Chip capacitor / 0603,15P±5%,50V,C0G,ROHS 1 C30
172 112-0631R0-R01 Chip capacitor / 0603,1P±0.25P,50V,C0G,ROHS 2 C4, C5
173 112-0635R0-R01 Chip capacitor / 0603,5P±0.25P,50V,C0G,ROHS 1 C34
174 112-0636R0-R01 Chip capacitor / 0603,6P±0.5P,50V,C0G,ROHS 1 C32
175 112-0637R0-R01 Chip capacitor / 0603,7P±0.5P,50V,C0G,ROHS 1 C10
176 112-0638R0-R01 Chip capacitor / 0603,8P±0.5P,50V,C0G,ROHS 1 C75
177 112-063R50-R01 Chip capacitor / 0603,0.5P±0.1P,50V,C0G,ROHS 2 C41, C111
178 112-072105-R01 Chip Ta capacitor/ TP Model, SIZE P,1uF±20%,10V,ROHS 2 C290, C415
179 112-072106-R01 Chip Ta capacitor/ TP Model, SIZE P,10uF±20%, 6.3V, ROHS 1 C327
180 112-072225-R01 Chip Ta capacitor/TP Model, SIZE P,2.2uF±20%, 10V, ROHS 3 C233, C237, C313
181 112-072475-R01 Chip Ta capacitor/TP Model, SIZE P,4.7uF±20%, 10V, ROHS 13
C1, C8, C42, C131, C159, C216, C226, C246, C278, C286, C345,
C346, C404
182 112-073334-R01 Chip capacitor/0805,0.33uF+80%--20%,10V,Y5V,ROHS 1 C181
183 112-102104-R01 Chip Ta capacitor/ TS Model, SIZE A, 0.1uF±20%, 35V, ROHS 2 C109, C113
184 112-102105-R01 Chip Ta capacitor/ TS Model, SIZE A,1uF±20%, 16V, ROHS 2 C117, C411
185 112-102156-R01 Chip Ta capacitor/TS Model, SIZE A,15uF±20%, 6.3V, ROHS 2 C137, C149
186 112-102475-R02 Chip Ta capacitor/ TS Model, SIZE A,4.7uF±20%, 16V, ROHS 1 C380
187 112-103100-R02
Chip monolithic ceramic capacitors / 1206,10P ± 5%,
1000V,C0G,ROHS
2 C44, C376
188 112-103102-R02
Chip monolithic ceramic capacitors / 1206,1000P ±
10%,1000V,C0G,ROHS
2 C29, C403
189 112-103106-R01 Chip capacitor / 1206,10uF+80%--20%,16V,Y5V,ROHS 1 C265
190 112-103150-R02
Chip monolithic ceramic capacitors / 1206,15P ±
5%,1000V,C0G,ROHS
1 C45
