PT8100 Service Manual
21
191 112-103180-R02
Chip monolithic ceramic capacitors / 1206,18P ±
5%,1000V,C0G,ROHS
1 C62
192 112-103220-R01
Chip monolithic ceramic capacitors / 1206,22P ±
5%,1000V,C0G,ROHS
1 C94
193 112-103270-R01
Chip monolithic ceramic capacitors / 1206,27P ±
5%,1000V,C0G,ROHS
1 C43
194 112-1032R0-R02
Chip monolithic ceramic capacitors / 1206,2P ±
5%,1000V,C0G,ROHS
1 C14
195 112-103300-R02
Chip monolithic ceramic capacitors / 1206,30P ± 5%,
1000V,C0G,ROHS
1 C46
196 112-1033R0-R02
Chip monolithic ceramic capacitors / 1206,3P ± 5%,
1000V,C0G,ROHS
1 C63
197 112-1035R0-R01
Chip monolithic ceramic capacitors / 1206,5P ± 5%,
1000V,C0G,ROHS
1 C152
198 112-1038R0-R02
Chip monolithic ceramic capacitors / 1206,8P ± 5%,
1000V,C0G,ROHS
1 C15
199 112-191477-R01
plug-in electrolytic capacitor / Ф 10*16,470UF25V, ±
20%,ROHS
1 C331
200 112-201476-R02
Chip electrolytic capacitor / Φ 6.3*5.3,47U25V, ±
20%,ROHS
3 C66, C341, C379
201 113-010100-R01 Chip trimming capacitor / TZV2Z100A110,3~10p+100,ROHS 2 C39, C122
202 114-06E180-R01
Chip Wire inductor / C1608CB-18NJ, ceramic 18NH ±
5%,0603,ROHS
1 L20
203 114-06E330-R01
Chip Wire inductor / C1608CB-33NJ, green，ceramic core ，
33NH±5%,0603,ROHS
2 L13, L45
204 114-06E470-R01
Chip Wire inductor / C1608CB-47NJ, green，ceramic core47NH
±5%,0603,ROHS
2 L36, L46
205 114-06E560-R01
Chip Wire inductor / C1608CB-56NJ, ceramic 56nH ±
5%,0603,ROHS
1 L53
206 114-06G102-R01 Chip inductor / MLF1608A1R0K,1uH±5%,0603,ROHS 1 L48
207 114-06G151-R01 Chip inductor / MLF1608DR15K,150nH±10%,0603,ROHS 1 L47
208 114-06G221-R02 Chip inductor / LGHK1608R22J-T,220nH±5%,0603,ROHS 3 L21, L27, L44
209 114-06G332-R01 Chip inductor / MLF1608A3R3K,3.3uH±5%,0603,ROHS 2 L5, L37
210 114-06G471-R01 Chip inductor / MLF1608DR47K,470nH±10%,0603,ROHS 1 L41
211 114-06G561-R01 Chip inductor / MLF1608DR56K,560nH±10%,0603,ROHS 1 L42
212 114-06G680-R01 Chip inductor / MLG1608B68NJ,68nH±5%,0603,ROHS 2 L14, L15
213 114-06G682-R01 Chip inductor / MLF1608E6R8K,6.8uH±10%,0603,ROHS 4 L2, L12, L34, L38
214 114-06G820-R01 Chip inductor / MLG1608B82N,82nH±5%,0603,ROHS 1 L7
215 114-07E180-R01 Chip Wire inductor / C2012C-18NJ,18nH±5%,0805,ROHS 1 L35
216 114-07E270-R01 Chip Wire inductor / C2012C-27NJ,27nH±5%,0805,ROHS 1 L3
217 114-07E390-R01 Chip Wire inductor / C2012C-39NJ,39nH±5%,0805,ROHS 2 L29, L57
218 114-07E470-R02 Chip Wire inductor / C2012C-47NG,47nH±2%,0805,ROHS 1 L58
219 114-07E560-R02 Chip Wire inductor / C2012C-56NJ,56nH±5%,0805,ROHS 1 L55
220 114-08E103-R01 Chip inductor / FSLM2520-100J,10uH±5%,1008,ROHS 1 L40
221 114-08E471-R01 Chip inductor / FSLM2520-R47K,470nH±10%,1008,ROHS 1 L49
222 114-08E821-R01 Chip inductor / FSLM2520-R82K,820nH±10%,1008,ROHS 1 L50
223 115-3R0110-R01
Chip air-cored coil / 0.9*3.0*11TR,
positive, high pin,
ROHS
1 L19
224 115-3R05R0-R05 Chip air-cored coil / 0.9*3.0*4.5TR, positive, ROHS 4 L9, L10, L11, L79
225 115-3R06R0-R02
Chip air-cored coil / 0.9*3.0*6TR,
positive, high pin,
ROHS
2 L18, L28
226 117-000000-R05 Chip bead / EMI,FILTER, SMT,BLM21P300S,0805,ROHS 3 L64, L72, L77
227 117-000000-R07 Chip bead / EMI,FILTER, SMT,BLM41P600SPT,1206,ROHS 2 L25, L26
228 117-000000-R08 Chip bead / EMI,FILTER, SMT,BLM11A601S,0603,ROHS 21
L1, L4, L22, L23, L24, L32, L33, L39, L51, L59, L60, L61,
L65, L66, L67, L69, L70, L74, L75, L76, L78
229 119-060104-R01 Thermistor / NTH5G16P42B104K07TH,100K,0603,ROHS 2 R90, R138
230 120-100000-R39C PT8200 Power Line with LV-2A jack, Length=3000mm, ROHS 1
231 120-100000-R42A
PT8000/PT8100 Power Line Unit main, with LV-2A jack and
SR,ROHS
1
232 120-400000-R14 black and white twisted-pair with jack,2.0*2P*70mm, ROHS 1
233 120-400000-R15 flat cable / 0.5*34P*60mm,ROHS 1
234 121-100000-R19 Speaker / 16Ω,7W,SANYO ,ROHS 1
235 122-116M80-R01 Chip TCXO / DSA535SA,16.8MHz±2.5PPm，ROHS 1 X1
236 122-13M580-R02 Chip crystal resonator / 3.58MHz,SMT-49,30PPM,ROHS 1 X2
237 122-19M830-R01 Chip crystal resonator/ 9.8304MHZ-NX5032GA,ROHS 1 X3
238 124-020000-R08 Chip connector / 08 6210 034 340 800, 34PIN, P=0.5mm, ROHS 1 CN4
239 124-050000-R16 3.5mm MIC socket / MOTOROLA, PJ-D3027, DC30V0.5A, ROHS 1 J1
240 124-090000-R01 Speaker socket / WCPW20-02,ROHS 2 CN2, CN3
