12
4. Technical information
4.1. Engine model and serial number
The engine model and serial number is located on the engine
as illustrated. These numbers are required when requesting
warranty and ordering parts. They are also referred to as engine
model and serial number because of their location.
4.2. Engine type
The Engines DV series engines are 90
0
V series water-cooled four-stroke diesel engines with direct
injection. It is turbocharged and After-cooled engine.
4.2.1. Cylinder block
The cylinder block is a single piece of alloy cast iron. To increase its stiffness, it is extended to a level
below the crankshaft center line. The engine has wet cylinder liners and individual cylinder heads with
struck-in valve seat rings and replaceable valve guides,
4.2.2. Piston con-rod / crankshaft
The forged crankshaft has detachable counterweights (Balance Weights). Radial oil seal is on crankshaft
at crank pulley and at flywheel end oil seal is on crank gear. Flywheel end and crank gear end is same for
the engine.
The con-rods (connecting rods) are die-forged, diagonally split and can be removed through the top of the
cylinders together with the pistons. Crankshaft and connecting rods run in steel-backed lead bronze
ready-to fit type bearings.
• Engine serial No. (eg. 2) : DV8
DV8.1002/0900001
Engine Serial No.
Production Year (2009)
Application Code
• Engine serial No. (eg. 1) : DV10
DV0.1002/0900001
Engine Serial No.
Production Year (2009)
Application Code
Year of Mfg.
PUNE,INDIA.
OIL ENGINES LTD.
OIL ENGINES LTD.
KIRLOSKAR
THIS ENGINE CONFIRMS TO ENVIRONMENT
THIS ENGINE CONFIRMS TO ENVIRONMENT
(PROTECTION)RULES 1986
Sr. No.
Rating Std.
Rating Kw/hp
ISO 3046
