14
Sr. No. Model Unit DV8 DV10 DV12
4.3 ENGINE SPECIFICATIONS FOR DV SERIES ENGINES
20 Lube Oil System Capacity lit. 44 47 57
21 Maximum Engine Inclination deg. 15 15 15
22 Rated Output Continuous - ISO 3046 kw. 360 448 559
23 Rated Output Standby - ISO 3046 kw. 394 495 613
24 Rated Speed rpm 1500 1500 1500
25 B. M. E. P at Rated Output bar 18.1 18.0 18.7
26 Overall Diamensions - L x W x H mm 1603 x 1125 x 1410 1793 x 1125 x 1410 1983 x 1125 x 1410
27 Dry Engine Weight
- With Flywheel & SAE1 Flywheel Hsg.
kg. 1508 1885 2262
28 Noise Level (dBA) at 1m dBA < 75 < 75 < 75
29 Exhaust Back Pressure - Max mm of Hg 50 50 50
30 Recommended Battery Capacity Ah 180 180 180
