KitchenAid KDDS 6010 - Plumbing Options - Double Models

OPTION 1
and Standpipe Ø38mm with Air Gap.
OPTION 2
with Waste Disposal. Standpipe
Ø38mm with Air Gap.
PLEASE NOTE: It is NOT recommended to
connect the to any part of the Waste
Disposal System.
OPTION 3
using Sink Trap with Drain Hose Joiner.
NOTE: Options 1 and 2 are the preferred options.
Drains will need to be separated to satisfy Kosher
requirements. We suggest you confirm acceptability
with your local Rabbi in respect to Kosher
installations.
R
R
R
R
Plumbing options - double models
WASTE
VALVE
WATER
SUPPLY
200mm
MINIMUM
BENDS RADIUS
FROM VALVE
POWER
OUTLET
WASTE
(750 mm - 882.5mm )
PRESA DI
ALIMENTAZIONE
WASTE
VALVE
WATER
SUPPLY
200mm
MINIMUM
BENDS RADIUS
FROM VALVE
POWER
OUTLET
WASTE
(750 mm - 882.5mm )
WATER
DISPOSAL
150mm MIN
PRESA DI
ALIMENTAZIONE
VALVE
WATER
SUPPLY
200mm
MINIMUM
BENDS RADIUS
FROM VALVE
POWER
OUTLET
WASTE
(750 mm - 882.5mm )
DRAIN
HOSE
JOINER
10
