WARNING!
DO NOT plug the product in at this stage.
Important!
DO NOT cut the inlet hose.
17 Connect the Inlet Hose to the water supply. Ensure the sealing
washer is in place. The hose coupling must be tightened a further
half turn after seal contact. TIP - Turn the water valve ON to
check for any leaks.
18 Ensure there is a power outlet in reach of the power supply cord.
If there is not a suitable outlet available then have one installed by
a qualified electrician.
NOTE: SINGLE MODELS DO NOT HAVE A TOE KICK TO INSTALL.
PROCEED TO STEP 11 FINAL CHECK LIST.
Step 7: connecting the inlet hose and power supply
19
19 Partially open the bottom drawer. Turn Prefinished Toe Kick
upside down and hold vertically against the bottom edge of the
Tub side (not the drawer front).
Mark the position of the bottom edge of the Tub side on the Toe
Kick.
Choose the nearest groove to the pencil mark which will result in
the shortest Toe Kick.
Step 8: measuring the toe kick
