KitchenAid KDTM404EWH Technical Education

4-2
n
KitchenAid 2015 Microltration Dishwashers
COMPONENT ACCESS
Insulation Blanket and Door Latch Strike
Installing Insulaon Blanket
(Stainless Steel Tub Models Only)
1. Fasten the blanket on the hooks located on each side of
the tub, (see Figures 1 and 2).
Figure 1
Figure 2
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
Removing Door Latch Strike
1. Open the dishwasher door.
2. Depress the 2 outside bars and pull out the latch, (see
Figures 1, 2 and 3).
Figure 1
Figure 2
Figure 3
