KitchenAid KDTM404EWH Technical Education

4-14
n
KitchenAid 2015 Microltration Dishwashers
COMPONENT ACCESS
3. Li o lower spray arm, (see Figure 3).
Figure 3
Lower Spray Arm Reinstallaon
1. Place spray arm on the diverter housing and slowly turn
spray arm unl it seats on diverter—making sure the
“corner arm” is pointed towards the front right corner of
the tub (see Figure 4).
2. Grasp lower spray arm nut and turn 1/4” clockwise to
secure in place on diverter housing.
3. Run the Diagnosc Cycle to verify spray arm operaon.
Nut
Corner Arm
Soaking Arm
Scrubbing Arm
Figure 4
To remove the lower spray arm:
1. Lower spray arm nut locaon, (see Figure 1).
Figure 1
2. Rotate the lower spray arm nut ¼ turn counter clockwise
to remove the spray arm, (see Figure 2).
Figure 2
Removing Lower Spray Arm
