COMPONENT ACCESS
KitchenAid 2015 Microltration Dishwashers
n
4-11
In Tub Components
Tub Component Identication
Water Level Float
Heater
Coarse Filter
Vent Outlet
Feed Tube to Middle and
Upper Spray Arms
Water Inlet
Interior LED Lighting
(available on some models)
Lower Spray Arm
ProScrub Manifold
