FAILURE
(Leftmost
2 Clock
Digits)
ERROR
(Rightmost
2 Clock
Digits)
MESSAGE/DESCRIPTION
SUGGESTED CORRECTIVE ACTION PROCEDURE
F2
Keypad
E0
E1
KEYPAD DISCONNECTED
STUCKOR SHORTEDKEY
PROCEDURE:
Beforeproceeding, press OFF, OFF, STARTtoenter the Diagnostic
mode and verify theerror codes.
A. Unplugovenor disconnect power.
B. Check keypad connector for firmconnection.
C. Replaceall partsand panels before operating.
D. Plug in oven or reconnectpower.
E. If error codereturns after 60 seconds proceed to step F.
F. Unplugovenor disconnect power.
G. Replace keypad.
H. Replaceall partsand panels before operating.
I.Plug in ovenorreconnect power. Wait60 seconds.
J. If error codereturns after60 seconds, proceed to step K.
K. Unplugovenor disconnect power.
L. Replace cable connectinguserinterfaceand keypad.
M. Replaceall partsand panels before operating.
N. Plug in oven or reconnect power. Wait 60 seconds.
O. If error codereturns after60 seconds, proceed to step P.
P. Unplugovenor disconnect power.
Q. Replace oven userinterface.
R. Replaceall partsand panels before operating.
S. Plug in oven or reconnect power. Wait 60 seconds.
T. Verifyoperation is normal. Press OFF, OFF, STARTtoreenter the Diagnostic
mode and complete checks.
FAILURE
(Leftmost
2 Clock
Digits)
ERROR
(Rightmost
2 Clock
Digits)
MESSAGE/DESCRIPTION
SUGGESTED CORRECTIVE ACTION PROCEDURE
F3
Sensors
E0
E3
MAIN OVEN SENSOR SHORTEDOROPEN
MEAT PROBESHORTED
PROCEDURE:
Before proceeding, press OFF, OFF,START to enterthe Diagnostic
modeand verify the errorcodes.
A. Verify in Diagnosticstemperature reading on sensor.
B. If dashes appearin maintemperature display proceedtostepC.
C. Unplugovenordisconnect power.
D. Removebackpanelsand ensure the indicated temperaturesensor is plugged
in properlyand fullyinserted. If not,plugin the connector and proceedtostepJ.
If sensorisplugged in properly proceedtostepE.
E. Check connector P2 on the appliance manager.EnsureP2 connector is
pluggedinproperly andfully inserted. If connectorisinserted properlygoto
step J. If not proceedtostepF.
F. Visually inspect the wires between P2 on the appliance managerand the
indicatedtemperature sensor.Make sure the wiresare not pinchedorcut. If
wires appear intact,unplugP2connector on the appliance manager.
Go to step G.
G. Measure the indicatedsensor resistance value(measure between appropriate
P2 connector pins). For the followingsensors, the resistancevalue should read:
Main OvenSensorBetween 931and 2869
Ω
.
(Approx.1080
Ω
at room temp.)
MeatProbe Sensor Between1,300 and103,000
Ω
.
(Approx.59,000
Ω
at room temp.)
(Insert meat probe into meat probe jack located
inside theoven cavity prior to readingresistance.)
If indicatedtemperaturesensor doesnot meet these requirementsproceed to
step H.
If indicatedtemperaturesensor does meetthese requirements proceed
to step J.
H. ForMAIN sensor:
Replace appropriatetemperature sensor. RepeatstepG.
If therequirementsare notmet, replace sensorharness. RepeatstepG.
If therequirementsare stillnot met,replace the meat probejack.
Repeat step G.
If the meat probe sensorisstill notoperating correctly go to step I.
I. Replace the appliancemanager.Ensureall connectorsare properlyplaced and
firmly connected
.
J. Replaceall parts and panels before operating.
K. Pluginovenorreconnect power. Wait 60 seconds.
L. Enterinto Diagnostic modeand read sensor formainoven sensor andmeat
probe on immediatedisplay.
F3
Sensors
E1
E2
LOWER MAIN OVEN SENSOR SHORTEDOROPEN
WARMING DRAWERSENSOR SHORTED
PROCEDURE:
Ovenisnot equippedwiththisfeature.If error occurs, before
proceeding press OFF, OFF,START to enterintoDiagnosticsmode and verify the
error codes. If error codereturns, replace userinterface with correct control
associatedwith this product.
