6-3. Mechanical Brake with Friction Clutch
The mechanical brake with friction clutch has both slip clutch and brake functions.
: IMPROPER electric chain hoist use could result in death or serious injury.
To avoid these hazards:
: NEVER disassemble and adjust the mechanical brake with friction clutch.
: ALWAYS contact your local KITO dealer in case of malfunction of mechanical
brake with friction clutch.
: When starting to lift, you may hear a slight sharp noise from the hoist.
This noise does not imply an abnormality of the hoist.
7. CONNECTION DIAGRAM
The electric instruments of the controller (contactor and converter) are installed on a panel and contained in
the hoist body.
To check the connection, open the controller cover of the hoist body. Make sure that lead wires are
connected correctly and firmly, referring to the following connection diagram.
: To avoid possible electric shock, ALWAYS make sure to turn off the power
source before checking the connection.
