KITO ED10ST User Manual

— 6 —
2. MAIN SPECIFICATIONS
Specifications and dimensions of AC120V type
Rated power source AC120V single phase, 50/60Hz
Type Single-speed type Dual-speed type Dual-speed cylinder type
Model ED06S ED10S ED18S ED16S ED24S ED48S ED06ST ED10ST ED18ST ED16ST ED24ST ED48ST EDC06SD EDC10SD EDC18SD EDC16SD EDC24SD
Rated load (kg) 60 100 180 160 240 480 60 100 180 160 240 480 60 100 180 160 240
Motor output (W) 300 600 300 600 300 600
Time rating (min) 15 10 20 15 15 10 20 15 15 10 20
Intermittent
duty
Duty rating (%ED) 30 20 30 30 20 30 30 20 30
Max. starting
frequenc
y
(times/h)
180 120 180 180 120 180 180 120 180
Rated current (A) 5 6 10 5 6 10 5 6 10
Lifting speed (m/min) 21 13 8 20 13.5 6.7
High
speed: 21
Low
s
p
eed: 4
High
speed: 13
Low
s
p
eed: 3
High
speed: 8
Low
s
p
eed: 3
High
speed: 20
Low
s
p
eed: 4
High
speed: 13.5
Low
s
p
eed: 3
High
speed: 6.7
Low
s
p
eed: 2
High
speed: 21
Low
s
p
eed: 4
High
speed: 13
Low
s
p
eed: 3
High
speed: 8
Low
s
p
eed: 3
High
speed: 20
Low
s
p
eed: 4
High
speed: 13.5
Low
s
p
eed: 3
Standard lift (m) 3 3 1.8
Push-button cord length: L (m) 2.5 2.5 -
Load chain diameter (mm) 4 4 4
Net weight (kg)
11.5
(12.0)*1
15.5
(16.0)*1
21
(21.5)*1
12.0
(12.5)*1
16.0
(16.5)*1
21
(21.5)*1
14.5
(15.0)*1
18.5
(19.0)*1
Min. headroom: C (mm) 315 330 520 315 330 520 945 960
Dimensions
(mm)
a 371 428 428 371 428 428 371 428
d 187 205 205 187 205 205 187 205
e 184 223 223 184 223 223 184 223
f 205 219 229 205 219 229 205 219
h 125 135 155 125 135 155 125 135
i 80 84 74 80 84 74 80 84
g 25 24 25 24 25
j 25 24 25 24 25
k 340 362 454 340 362 454 340 362
m 92 149 92 149 92
※1: these net weight at control voltage of 30V
Single-speed type
Dual s
p
eed-t
yp
e
Dual-speed cylinder type

KITO ED10ST Specifications
