— 7 —
Specifications and dimensions of AC240V type
Rated power source AC240V single phase, 50/60Hz
Type Single-speed type Dual-speed type Dual-speed cylinder type
Model ED06S ED10S ED18S ED16S ED24S ED48S ED06ST ED10ST ED18ST ED16ST ED24ST ED48ST EDC06SD EDC10SD EDC18SD EDC16SD EDC24SD
Rated load (kg) 60 100 180 160 240 480 60 100 180 160 240 480 60 100 180 160 240
Motor output (W) 300 600 300 600 300 600
Time rating (min) 20 15 20 20 20 15 20 20 20 15 20
Intermittent
duty
Duty rating (%ED) 30 20 30 30 20 30 30 20 30
Max. starting
frequenc
y
(times/h)
180 120 180 180 120 180 180 120 180
Rated current (A) 3 5 3 5 3 5
Lifting speed (m/min) 21 13 8 20 13.5 6.7
High
speed: 21
Low
s
p
eed: 4
High
speed: 13
Low
s
p
eed: 3
High
speed: 8
Low
s
p
eed: 3
High
speed: 20
Low
s
p
eed: 4
High
speed: 13.5
Low
s
p
eed: 3
High
speed: 6.7
Low
s
p
eed: 2
High
speed: 21
Low
s
p
eed: 4
High
speed: 13
Low
s
p
eed: 3
High
speed: 8
Low
s
p
eed: 3
High
speed: 20
Low
s
p
eed: 4
High
speed: 13.5
Low
s
p
eed: 3
Standard lift (m) 3 3 1.8
Push-button cord length: L (m) 2.5 2.5 -
Load chain diameter (mm) 4 4 4
Net weight (kg)
11.5
(12.0)*1
15.5
(16.0)*1
21
(21.5)*1
12.0
(12.5)*1
16.0
(16.5)*1
21
(21.5)*1
14.5
(15.0)*1
18.5
(19.0)*1
Min. headroom: C (mm) 315 330 520 315 330 520 945 960
Dimensions
(mm)
a 364 428 428 364 428 428 364 428
d 187 205 205 187 205 205 187 205
e 177 223 223 177 223 223 177 223
f 205 219 229 205 219 229 205 219
h 125 135 155 125 135 155 125 135
i 80 84 74 80 84 74 80 84
g 25 24 25 24 25
j 25 24 25 24 25
k 340 362 454 340 362 454 340 362
m 92 149 92 149 92
1: these net weight at control voltage of 30V
Notes: (1) The power supply cable is 2mm² × 5m (3 conductors).
(2) Hoisting speed is the average value of wind-up and -down speed under related voltage, rated frequency, and rated load conditions. Speed
may differ by voltage and load conditions.
(3) Non-standard lengths of lift (load chain) and push-button cord of the single- and dual-speed types are also available upon request.
: NEVER use the hoist with power source voltage exceeds rated voltage by more
than 10%. (Refer to Sec. 3-2)
Additionally, these 3 types of electric chain hoists are available for normal voltage operation and low-voltage
(30V) operation. Further, these chain hoists can be used under the different voltages as shown in next page.
The lifting speed varies according to the actual power source voltage as shown in next page.
CAUTION
