— 37 —
Fig No. Part No. Part Name
Nos.
Per Hoist
Capacity
60kg 100kg 180kg 160kg 240kg
42
E2D162 Socket bolt with spring washer 4 Note 1 Note 2 Note 1 Note 3
E3D451 Socket bolt with spring washer 4 Note 4 Note 5 Note 4 Note 6
43 E2D221 Oil seal 1
44 E2D222 Needle roller bearing 1
45 E2D231 Ball bearing 2
46 E2D1223 Gear #2 assembly 1
47 E2D238 Ball bearing 1
48 E2D236 Oil seal 1
49 E2D5234 Friction clutch assembly (incl. Load sheave) 1
50 E2D311 Set spring 1
51 E2D239 Oil seal 1
52 E2D125 Gear case packing 1
53 E2D105 Gear case 1
54 E2D152 Socket bolt with spring washer 4
55 E2D104 Controller cover 1
56 E3D801 Name plate B 1
57 E2D109 Controller cover packing 1
58 E2D151 Machine screw with spring washer 3
59 E2D841 Load chain 1
60 E2D865 Warning seal EO 1
61 E2D866 Warning seal EE 1
62 E2D867 Warning seal EF 1
Note 1: Lot No before that of Note 4
Note 2: Lot No before that of Note 5
Note 3: Lot No before that of Note 6
Note 4: Lot No on & after 6ASY8681
Note 5: Lot No on & after 6ASY8680
Note 6: Lot No on & after 6ASY8312
When either of ‘10 Body’ or ‘42 Socket bolt with spring washer’ is ordered, please also the counterpart of it.
To Next Page
