KITO ED10ST - Page 42

— 40 —
Fig No. Part No. Part Name
Nos.
Per Hoist
Capacity
60kg 100kg 180kg 160kg 240kg
66 E2D041 Chain pin 1
67 E2D049 Slotted nut 1
68 E2D096 Split pin 1
69 E2D1831 Chain container (3m lift for cylinder type) 1
70 E2D854 Socket bolt BP 1
71 E2D853 U nut 1
72 E2D852 Split pin 1
73 E2D861 Clamp 1
74* E2DC1607 Push button cord 7C complete set 1
75
―――
Push button cord 7C assembly 1
76 E2D537 Cable holder C 1
77 E2D525 Cable packing C12 1
78 E2D5041 Detachable fitting E 1
79 E2D1002 Detachable hook assembly 1
80 E2D1071 Hook latch assembly 1
81 E2D555 Machine screw with spring washer 3
82
―――
Flat head screw 1
83
―――
Flat head screw 1
84 E2D865 Warning seal EO 1
85 E2D866 Warning seal EE 1
86 E2D867 Warning seal EF 1
87 E2D931 Warning tag LD 1
88 E2D870 Chain stopper link 1
90
E3D1411 Limit switch assembly 1
E3D1411-C Limit switch assembly *
1
1
91 E3D422 Socket bolt with spring washer 2
* This complete set differs depending on power voltage and/or control voltage.
*1: For ‘Control panel complete set’ equipped with reverse-operation protection board.
