KITO EQ series Assembly/Disassembly Manual

7
Figure #
Part Number
Part Name Remark
A1 001
Suspension eye
A2 121
Top pin
A3 033
Machine screw socket bolt For Top pin
A4 5501
Body with stator
A5 238
Ball bearing
A6 137
Set pin S
A7 820
Warning sticker HW
A8 960
Name plate load side E
A9 1223
Friction clutch complete set
A10 244
Oil seal
A11 241
Load sheave
A12 242
Ball bearing
A13 245
Oil seal
A14 243
Ball bearing
A15 207
Snap ring
A16 240
Load gear
A17 208
Snap ring
A18 187
Packing
A19 153
Cable holder
A20 5505
Braking resister assembly
A21 194
Machine screw with spring washer For Braking register
A22 151
Limit switch cord cover
A23 152
Machine screw with spring washer For Limit switch cord cover, Cable holder
A24 331
Chain guide
A25 1060
Limit switch complete set
A26 333
Limit switch cover
A27 335
Machine screw
A28 165
Machine screw socket bolt For Chain guide
A29 110
Gear case
A30 239
Ball bearing
A31 133
Oil plug
A32 136
Plug packing
A33 810
Name plate OF
A34 815
Name plate SP
A35 167
Machine screw socket bolt For Gear case (shorter)
A36 162
Machine screw socket bolt For Gear case (longer)
A37 116
Packing G
A38 135
Oil plug B
A39 173
Eyebolt packing
A40 107
Fan cover
A41 164
Socket bolt For Fan cover
A42 225
Toothed lock washer For Fan cover
A43 108
Fan
A44 323
Snap ring
A45 106
Motor cover
A46 163
Machine screw socket bolt For Motor cover
A47 209
Ball bearing
A48 5212
Brake drum assembly
A49 214
Brake spring
A50 324
O ring
A51 318
Collar
A52 317
Thrust disc
A53 503
Pull rotor
A54 316
Coned disc spring
A55 5502
Motor shaft with rotor
