Kitz RDH Series User Manual

14/31
DocumentNo.:KE-4051-00


3.Wiring


Inordertopreventelectricshock:
 Turnoffthepowersupplybeforeperformingelectricwiring.
 Aftercompletingwiring,closetheterminalboxcoverbytighteningthescrews.
 Performelectricwiringinaplacenotsubjecttosplashingofrainwater.

 DONOTforciblypulltheconnectingcablesandwiresastheymaygetdisconnectedandcause
electricshock.Allowsomeslackinthecablewhenconnectingtheactuatortothepowersource
(Fig.15).





Fig15




 DONOTperformwiringinaplacewithhighhumidity.
 DONOTmodifytheproduct.Itmayresultinafunctionalfailure.
 DONOTseparatetheactuatorfromthevalve.Itmaydamagetheactuator.
 DONOTlosethesealgasket(madeofchloroprenerubber)installedintheterminalboxcoverfor
dustprevention. 
 DONOTscratchthecontactsurfaceofthesealgasket.Itwillimpairthesealingperformance.
 DONOTlosethesetscrewsusedfortheterminalboxcover.

 Wiringworkmustbeperformedbyalicensedelectricianoraskilledengineer.
 This product is designed for 24VDC. Check that the power supply is suitable for use with this
product.
 Performwiringworkproperlytopreventaccidents causedbyshort-circuit,etc.
 Follow the instructions on the nameplate when performing a wiring work. Incorrect wiring may
damagetheelectricalcomponents.
 Makesuretothoroughlysealthecableconnector,cablegland,terminalboxconduitporttoprevent
waterintrusiontotheactuatorandtheterminalbox.Insufficientsealingmayresultincorrosionand
malfunction,etc.
 Performwiringawayfromloadinductorandhighvoltagedevices.
 Insulatethecorewirebycuttingtheedgeofthecorewiretopreventelectricshock,shortcircuit,
etc.
 Keepotherpowersupplycablesandpowercablesawayfromthecablesofthisproducttopreventa
malfunctioncausedbynoise.
 Take appropriate measures for noise and adjust the instruction output period of the controller.
Otherwise,itmayleadtoshortlifeoftheproduct.

NoNo
Yes
Slackthecable
.
Slackthecable.
Yes
