2
GENERAL SPECIFICATIONS
Klein Tools CL900 is an auto-ranging, true root mean square (TRMS)
digital clamp meter that measures AC/DC current via the clamp and
measures AC/DC voltage, resistance, continuity, frequency, duty-
cycle, capacitance, and tests diodes via test-leads. It features a Low
Impedance (LoZ) mode for identifying and eliminating ghost or stray
voltages, and has a dedicated mode for capturing Inrush Current.
• Operating Altitude: 6562 ft. (2000m)
• Relative Humidity: <80% non-condensing
• Operating Temperature: 32° to 122°F (0° to 50°C)
• Storage Temperature: 14° to 140°F (-10° to 60°C)
• Accuracy: Values stated at 65° to 83°F (18° to 28°C)
• Temp Coefcient: 0.1 x (Quoted Accuracy) per °C above
28°C or below 18°C, corrections are required when ambient
working temp is outside of Accuracy Temp range
• Dimensions: 10.4" x 3.9" x 1.7" (265 x 99 x 43 mm)
• Weight: 18.6 oz. (526 g) including batteries
• Calibration: Accurate for one year
• Standards: Conforms to UL STD 61010-1, 61010-2-032,
61010-2-033.
Certified to CSA STD C22.2 # 61010-1,
61010-2-032, 61010-2-033.
IEC EN 61010-1, 61010-2-032,
61010-2-033.
• Pollution degree: 2
• Accuracy: ± (% of reading + # of least significant digits)
• Drop Protection: 6.6 ft. (2m)
• Safety Rating: CAT IV 600V, CAT III 1000V, Class 2,
Double insulation
CAT III: Measurement category III is applicable to test and
measuring circuits connected to the distribution part of the
building’s low-voltage MAINS installation.
CAT IV: Measurement category IV is applicable to test and
measuring circuits connected at the source of the building’s
low-voltage MAINS installation.
• Electromagnetic Environment: IEC EN 61326-1. This
equipment meets requirements for use in basic and controlled
electromagnetic environments like residential properties,
business premises, and light-industrial locations.
Specifications subject to change.
ENGLISH
