8
ENGLISH
FUNCTION BUTTONS
MAX/MIN
When the "MAX/MIN" button
8
is pressed, the meter keeps track of
the Maximum and Minimum values as the meter continues to take
samples.
1. When measuring, press "MAX/MIN" button
8
to toggle between
the Maximum value (MAX) and Minimum value (MIN). If a new
Maximum or Minimum, the display will update with the new value.
2. Press "MAX/MIN" button
8
for more than one second to return to
normal measuring mode.
INRUSH CURRENT
Rotate the Function Selector switch
2
to the Current
A
setting
and
press INRUSH
10
prior to an inrush event to test for inrush
current. While the meter monitors current waiting for the inrush
event, "----" will be visible on the display.
NON-CONTACT VOLTAGE TESTING
Press and hold the "NCV" button
13
to test for AC voltage using the
integrated non-contact voltage tester. Approach the conductor under
test leading with the sensing antenna
14
. The meter delivers visual
warning signals via the LED indicator
15
and audible signals (beeps)
when AC voltage is detected. Release the "NCV" button to exit NCV
testing mode.
NOTE: It is not recommended to perform continuity and NCV testing
simultaneously, as both tests utilize the same audible signal, making
it difficult to resolve which test is responsible for the audible alarm.
NOTE: Only voltages of 90V AC or greater will be detected.
