TPU LAN Configuration Setup C-9
SonarPro needs to know the
IP address of the TPU. Start
SonarPro, and then click
to connect to the towfish in
real time. The TPU
Connection dialog box will
open. Enter the TPU IP
address into the dialog box if
different.
The LAN configuration should now be complete.
While you have the TPU Connection dialog box open, click
Change the Sonar Channel Configuration and verify the
settings in the Channels and Sensors dialog box as shown.
