Computer Display and Control Unit 2-3
2.2.6 RS-232 COM 2 Port
Quantity: 1
Baud rate: 4800 baud
Connector: 9-pin DSUB for receiving navigation
data
2.2.7 LAN Input/Output Port
Quantity: 1
Output: 100BaseT
Connector: RJ-45
2.2.8 Power Input
Power consumption: 250 VA (nominal)
Input voltage: 115 VAC, 50–60 Hz or 230 VAC,
50–60 Hz, manually selected
2.2.9 Physical Characteristics
Size: 48.3 cm (19 in.) wide
8.75 cm (3.5 in.) high
54.6 cm (21.5 in.) deep
Weight: 10.4 kg (23 lb)
2.3 Computer Display and Control Unit
For specifications on the Computer Display and Control Unit, please refer to the
manufacturer's manual.
2.4 Ethernet Hub
For specifications on the Ethernet Hub, please refer to the manufacturer's manual.
