2.1.1 Cooling circuit
Evaporator (5)
- Plate heat exchanger made of high-quality steel, copper soldered type.
Water tank (55)
- High-quality steel type, tank atmospheric open, covered, insulated for
condensation water, provided with discharge connection, water level
indicator, and built-in float switch for water level monitoring and filling.
Centrifugal pump (60)
- Multistage normal-suction horizontal high-pressure centrifugal pump of
block-unit design, made of plastics.
Pipe system
- Provided with fittings, made of plastics hose (PUN-hose).
The heat generated at the load is supplied to the cooler via the cooling water
circuit. The cooling down of the water takes place in the evaporator (5) by way
of heat release. After cooling down, the cold water is supplied to the tank (55)
and is supplied back to the load via the pump (60) provided in the cooling
water circuit
(see also section 13- Flow diagram)
