SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Technical specifications SOFT 100
Nominal heat input
kW (Kcal/h)
10,3 (8.858)
Reduced heat input
kW (Kcal/h)
2,7 (2.322)
Nominal heat output
kW (Kcal/h)
9,56 (8.222)
Reduced heat output
kW (Kcal/h)
2,55 (2.193)
Efficiency at nominal heat output
%
92,5
Efficiency at reduced heat output
%
94,5
CO at 13% oxygen at nominal heat output
%
0,008
CO at 13% oxygen at reduced heat output
%
0,054
Maximum power uptake
Watt
340*
Power uptake when running
Watt
32
Nominal voltage
V
230
Nominal frequency
Hz
50
Flue outlet diameter
mm
80
Air intake pipe diameter
mm
50
Minimum chimney draught at nominal heat output
Pa
10,6
Minimum chimney draught at reduced heat output
Pa
9,8
Combustion gas mass at nominal heat output
g/s
6,6
Combustion gas mass at reduced heat output
g/s
3,5
Pellet tank capacity
kg
24
Average exhaust flue gas temperature at nominal heat output
°C
122
Average exhaust flue gas temperature at reduced heat output
°C
60
Width
mm
480
Height
mm
1100
Depth
mm
525
Minimum safety distance from flammable materials (side/rear/front)
mm
200 / 200 / 800
Weight
kg
155
* Power consumption only during the ignition cycle.
The appliance’s heat output may vary in relation to the type of pellets used.
Pellet properties
The appliance has been tested with all types of pellets available on the market. The pellets must have the following
properties:
- Diameter 6 mm.
- Maximum length 35 mm.
- Maximum humidity content 8–9 %.
- Made of 100% wood. Totally additive-free.
- Maximum ash residue 1.1 %.
To obtain optimal efficiency from the appliance, we recommend using good quality pellets. Pellets should be poured
into the tank using a shovel, and not directly from the bag.
