SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Parameter tables SOFT 100
“CLEANER SETTINGS” parameters - Model S100 (L09_161018)
Parameter
Menu level
Description
Display wording
Measurement
Value field
Database
P0
Pr51
M10 – 01 – 01
ON time for brazier cleaning gearmotor
CLEANER DURATION
Seconds
0 – 120
13
Pr52
M10 – 01 – 02
Time from switching off after which the brazier cleaning cycle starts
CLEANER DELAY
Minutes
1 – 15
6
Pr53
M10 – 01 – 03
Time from switching on after which the brazier cleaning cycle starts
CLEANER STAND-BY
Hours
1 – 24
9
“DUCTING SETTINGS” parameters - Model S100 (L09_161018)
Parameter
Menu level
Description
Display wording
Measurement
Value field
Database
P0
Pr55
M10 – 03 – 01
Enables ducting operation
ENABLE DUCT.
Off / Mode
Off
S1 – S2 – S1+2
T1 – T2 – T1+2
A1 – A2 – A1+2
A1
Pr56
M10 – 03 – 02
Allows for choosing whether the ducted air fans can be switched “OFF”.
DUCTED OFF
On – Off
On – Off
On
Pr57
M10 – 03 – 03
Heat exchanger 2 (ducting 1) in power 1 work phase
DUCT.1 SPEED-S1
Volt
65 – 225
150
Pr58
M10 – 03 – 04
Heat exchanger 2 (ducting 1) in power 2 work phase
DUCT.1 SPEED-S2
Volt
65 – 225
160
Pr59
M10 – 03 – 05
Heat exchanger 2 (ducting 1) in power 3 work phase
DUCT.1 SPEED-S3
Volt
65 – 225
170
Pr60
M10 – 03 – 06
Heat exchanger 2 (ducting 1) in power 4 work phase
DUCT.1 SPEED-S4
Volt
65 – 225
180
Pr61
M10 – 03 – 07
Heat exchanger 2 (ducting 1) in power 5 work phase
DUCT.1 SPEED-S5
Volt
65 – 225
195
Pr62
M10 – 03 – 08
Heat exchanger 3 (ducting 2) in power 1 work phase
DUCT.2 SPEED-S1
Volt
65 – 225
65
Pr63
M10 – 03 – 09
Heat exchanger 3 (ducting 2) in power 2 work phase
DUCT.2 SPEED-S2
Volt
65 – 225
65
Pr64
M10 – 03 – 10
Heat exchanger 3 (ducting 2) in power 3 work phase
DUCT.2 SPEED-S3
Volt
65 – 225
65
Pr65
M10 – 03 – 11
Heat exchanger 3 (ducting 2) in power 4 work phase
DUCT.2 SPEED-S4
Volt
65 – 225
65
Pr66
M10 – 03 – 12
Heat exchanger 3 (ducting 2) in power 5 work phase
DUCT.2 SPEED-S5
Volt
65 – 225
65
“GENERAL SETTINGS” parameters - Model S100 (L09_161018)
Parameter
Menu level
Description
Display wording
Measurement
Value field
Database
P0
Pr38
M10 – 04 – 01
Re-start block
RESTART BLOCK
Minutes
0 – 10
5
Pr39
M10 – 04 – 02
Time for considering the device off
OFF TIME
Minutes
0 – 20
10
Pr40
M10 – 04 – 03
Pre-loading time in ignition
PRE-LOAD START
Seconds
0 – 255
215
Pr41
M10 – 04 – 04
Stand-by time after pre-loading
AFTER PRE-LOAD
Seconds
0 – 255
230
Pr42
M10 – 04 – 05
Extractor speed in pre-loading phase
PRE-LOAD SMOKE
SPEED
Rpm
350 – 2800
2300
Pr43
M10 – 04 – 06
Temperature delta on “SET ROOM” for automatic switching on/off
DELTA ON-OFF
°C
0.0 – 10.0
1.0
Pr44
M10 – 04 – 07
Automatic switch-off delay (timer after reaching “SET ROOM”)
AUTO OFF DELAY
Minutes
2 – 120
10
Pr45
M10 – 04 – 08
Power change delay
POWER CHANGE
Seconds
0 – 240
60
Pr46
M10 – 04 – 09
Heat exchanger 1 speed (primary) in the switch-off phase
AIR SPEED OFF
Volt
65 – 225
195
Pr47
M10 – 04 – 10
Keypad lock enabling
KEY LOCK
On – Off
On – Off
Off
Pr48
M10 – 04 – 11
Time after which an alarm is triggered in the event of a blackout
BLACK OUT TIME
Seconds
0 – 60
30
Pr49
M10 – 04 – 12
Time after which the “NO PELLET” alarm triggers if “PELLET RESERVE”
ALARM RESERVE
Minutes
1 – 180
60
Pr50
M10 – 04 – 13
Enabling of the pellet level sensor (only on configured models)
PELLET RESERVE
On – Off
On – Off
Off
