SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
“FACTORY SETTINGS” parameters - Model S100 (L09_161018)
Parameter
Menu level
Description
Display wording
Measurement
Value field
Database
P0
Pr01
M10 – 05 – 01
Ignition cycle maximum time
START TIME
Minutes
5 – 25
18
Pr02
M10 – 05 – 02
Time for flame stabilisation after ignition
FL. LIGHT TIME
Minutes
0 – 15
9
Pr03
M10 – 05 – 03
Time interval between the two brazier cleaning cycles
CADENCE CLEANING
Minutes
3 – 240
60
Pr04
M10 – 05 – 04
Auger gearmotor ON time in ignition phase
AUGER START
Seconds
0.1 – 8.0
0,8
Pr05
M10 – 05 – 05
Auger gearmotor ON time during the stabilisation phase
AUGER FL. LIGHT
Seconds
0.1 – 8.0
1,2
Pr06
M10 – 05 – 06
Auger gearmotor ON time in power 1 work phase
AUGER POWER 1
Seconds
0.1 – 8.0
2,0
Pr07
M10 – 05 – 07
Auger gearmotor ON time in power 2 work phase
AUGER POWER 2
Seconds
0.1 – 8.0
2,6
Pr08
M10 – 05 – 08
Auger gearmotor ON time in power 3 work phase
AUGER POWER 3
Seconds
0.1 – 8.0
3,2
Pr09
M10 – 05 – 09
Auger gearmotor ON time in power 4 work phase
AUGER POWER 4
Seconds
0.1 – 8.0
4,0
Pr10
M10 – 05 – 10
Auger gearmotor ON time in power 5 work phase
AUGER POWER 5
Seconds
0.1 – 8.0
4,9
Pr11
M10 – 05 – 11
Time after which the alarm is signalled following an anomaly
ALARMS DELAY
Seconds
0 – 120
90
Pr12
M10 – 05 – 12
Brazier cleaning duration
CLEANING DURATION
Seconds
0 – 120
60
Pr13
M10 – 05 – 13
Minimum temperature of the combustion chamber in order to consider the
appliance on
MINIMUM THRESHOLD
°C
70 – 280
180
Pr14
M10 – 05 – 14
Maximum temperature of the combustion chamber
MAXIMUM
THRESHOLD
°C
200 – 880
800
Pr15
M10 – 05 – 15
Combustion chamber temperature threshold for starting the air
exchangers
BLOWER THRESHOLD
°C
100 – 720
180
Pr16
M10 – 05 – 16
Smoke extraction speed in ignition phase
SMOKE SP. START
Rpm
500 – 2800
2100
Pr17
M10 – 05 – 17
Smoke extraction speed in start phase
SMOKE SP. FL. LIGHT
Rpm
500 – 2800
2000
Pr18
M10 – 05 – 18
Smoke extraction speed in power 1 work phase
SMOKE SPEED P1
Rpm
500 – 2800
1600
Pr19
M10 – 05 – 19
Smoke extraction speed in power 2 work phase
SMOKE SPEED P2
Rpm
500 – 2800
1750
Pr20
M10 – 05 – 20
Smoke extraction speed in power 3 work phase
SMOKE SPEED P3
Rpm
500 – 2800
1950
Pr21
M10 – 05 – 21
Smoke extraction speed in power 4 work phase
SMOKE SPEED P4
Rpm
500 – 2800
2150
Pr22
M10 – 05 – 22
Smoke extraction speed in power 5 work phase
SMOKE SPEED P5
Rpm
500 – 2800
2300
Pr23
M10 – 05 – 23
Heat exchanger 1 (primary) speed in power 1 work phase
AIR SPEED P.1
Volt
65 – 225
150
Pr24
M10 – 05 – 24
Heat exchanger 1 (primary) speed in power 2 work phase
AIR SPEED P.2
Volt
65 – 225
160
Pr25
M10 – 05 – 25
Heat exchanger 1 (primary) speed in power 3 work phase
AIR SPEED P.3
Volt
65 – 225
170
Pr26
M10 – 05 – 26
Heat exchanger 1 (primary) speed in power 4 work phase
AIR SPEED P.4
Volt
65 – 225
180
Pr27
M10 – 05 – 27
Heat exchanger 1 (primary) speed in power 5 work phase
AIR SPEED P.5
Volt
65 – 225
195
Pr28
M10 – 05 – 28
Combustion chamber temperature threshold for considering the device off
THRESHOLD OFF
°C
50 – 250
170
Pr29
M10 – 05 – 29
Smoke extraction speed in the brazier cleaning phase
SMOKE SP. CLEANING
Rpm
700 – 2800
2800
Pr30
M10 – 05 – 30
Auger gearmotor ON time in the cleaning phase
AUGER CLEANING
Seconds
0.0 – 8.0
1,0
Pr31
M10 – 05 – 31
Enabling of a primary room temperature probe connected to the board
MOTHERBOARD
PROBE
On – Off
On – Off
Off
Pr32
M10 – 05 – 32
Pre-heating time
PREHEAT TIME
Seconds
0 – 250
0
Pr33
M10 – 05 – 33
PELLET CRUISE CONTROL modulation threshold
CRUISE THRESHOLD
°C
120 – 880
560
Pr34
M10 – 05 – 34
Temperature delta on PELLET CRUISE CONTROL modulation threshold
CRUISE DELTA
°C
20 – 60
40
Pr35
M10 – 05 – 35
PELLET CRUISE CONTROL modulation time
CRUISE TIME
Minutes
1 – 10
3
Pr36
M10 – 05 – 36
Time after which the intervention of the Technical Assistance Centre is
requested
SERVICE HOURS
Hours
Off
260 – 2800
2000
“RELAX SETTINGS” parameters - Model S100 (L09_161018)
Parameter
Menu level
Description
Display wording
Measurement
Value field
Database
P0
Pr150
M10 – 10 – 01
Heat exchanger 1 (primary) speed during the work phase with “RELAX
FUNCTION” enabled
RELAX AIR SPEED
Volt
Off
65 – 225
Off
Pr151
M10 – 10 – 02
“RELAX FUNCTION” activation time
RELAX TIME
Minutes
30 – 254
On
30
