SOFT 80, SOFT 100 PELLET-BURNING STOVE
ELECTRICAL CONNECTION
The electric connection must only be performed by qualified staff, in compliance with all general and local safety
regulations.
Check that the power supply voltage and frequency correspond to 220 V –
50 Hz.
The appliance’s safety is ensured when it is properly connected to an efficient earthing system.
When making the electric connection to the mains power
supply, include a 6 A – Id 30 mA magnetothermic residual-
current device with suitable breaking load. The electric connections, including the earth connection, must be made after
shutting off the electrical system.
When completing the system, bear in mind that the cables must be laid in an unmovable manner and far from parts
subject to high temperatures. During the final wiring of the circuit, only use components with a suitable electrical
protection rating. Do not pass electrical cables in the immediate vicinity of the flue gas pipe, unless they are insulated
with suitable materials.
KLOVER S.r.l. declines all responsibility for injury to persons and animals or damage to objects due to failure to
earth the appliance or to comply with IEC specifications.
Connection to the room thermostat
One or more terminal blocks are located behind the appliance to connect any room thermostats (refer to “Components of
the appliance”).
The table below describes the operation of the terminal blocks found on the rear panel of the appliance.
Terminal
block
Description Type of management Action
1 Main room Only with room thermostat *
With the contact CLOSED, the appliance continues to work at the set power,
regardless of the SET ROOM (button 1) value and the status of any other room
thermostats or probes connected.
With the contact OPEN, the appliance enters the modulation mode, provided
that the room temperature set in SET ROOM (button 1) is fulfilled and that any
other room thermostats or probes connected are fulfilled.
* Connect a non-powered room thermostat to manage a simple dry contact and, preferably, with a settable hysteresis
value.
