SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Use the appropriate cleaning hook for the front scraper to pull out the front rod and then move it forward and backwards
to clean off combustion residues from the air exchanger (Figure 1). Suck up the residual ash deposited above the flame
separator (Figure 2).
Remove the brazier covering ring and the grille then eliminate the combustion residues (Figures 3 and 4).
1
2
3
4
