3.2.4.1.2.4 Calibration gearposition Analog aux
In this menu, you can then specify the output voltages corresponding to the various gears. The input
channel for the gearposition must be set in the hardware configuration, you can choose between
analog aux input 1 to 3. A gearposition sensor must be present with a voltage range between 0 and
5V. In the top row, the various gears (from reverse to 8
th
gear) can be selected. The second row
contains the corresponding sensor output voltages to the various gears.
The gearposition sensor output voltages can be set manually or automatically. For automatic
calibration of the voltages, please select „Automatic calibration gearposition‟. The software will tell
the user which gear to select and to press „ok‟ to calibrate the output voltage for that gear. Before
using the automatic calibration, the gears (reverse to 8
th
gear) must be selected in the top row
using the drop down menu‟s.
