KMS MD35 - 8 Wiring Diagram MD35

KMS MD35 manual
Version 4.16 71
8 Wiring diagram MD35
Standard colours KMS management MD35 wiring loom
Pin nr. KMS
Colour
Length
Diameter: 0,5mm²
Diameter: 0,75mm²
Function
1
red
*
CAN High
2
green
*
CAN Low
3
orange/black
*
Boost Control
4
yellow/red
*
Idle Control
5
white/black
*
Fuel pump relay
6
yellow/green
*
Diagnostic out / Ignition output 6
7
blue
*
Aux 1 out
8
pink
*
Aux 2 out
9
yellow/red
*
Aux 3 out
10
white/black
*
Power output2: Injector output 2 / A.L.S.
11
white
*
Injector output 1
12
red
*
12V injector supply
13
orange
*
Ignition output 1
14
green
*
Ignition output 2
15
purple
*
Ignition output 3
16
pink
*
Ignition output 4
17
blue
*
Ignition output 5
18
red/black
*
Tacho output
19
black
*
Sensor ground: water / air / MAP / TPS / etc.
20
yellow
*
5V sensor supply
21
yellow/black
*
Launch control
22
green/red
*
Powershift / Airco
23
black
*
ECU ground
24
orange/red
*
Analog aux 3: A.L.S. / launch / gearpos / map selector / EGT(1)
25
purple/red
*
Analog aux 2: A.L.S. / launch / gearpos / map selector / EGT(2)
26
pink/black
*
Oil pressure signal
27
grey/blue
*
Water temperature signal
28
red/blue
*
Air temperature signal
29
grey/black
*
MAP signal
30
grey
*
TPS signal
31
white
*
Lambda signal 1
32
white/red
*
Analog aux 1: Lambda signal 2 / gearpos / map selector
33
red
*
Crank-sensor signal inductive
34
red/green
* (shielded)
Hall input: Crank / Cam
35
red
*
12V ECU
