Kobalt KHV24 - Operating Instructions

OPERATING INSTRUCTIONS - INFLATION
CAUTION
• This inator is not a toy - do not aim at yourself or others.
WARNING
• Please read, understand and follow all warnings before using this inator.
• The High-Volume Inator is designed for air mattresses, rafts, beach toys and other high volume
inatables. Use Extra Caution if using to clean debris from workspaces. Do not aim at yourself,
others or pets.
• Read and follow all manufacturers’ instructions and warnings for the item you are inating.
2
F
D
B
B
F
D
2. To Inate
• Make sure that Ination Port (C) is pointed away
from yourself and others
(see WARNING on page 6).
• Firmly snap the Kobalt 24V Max Battery into
place (see page 7) for more details.
• Select the appropriate size nozzle from the
Tethered Nozzle Set (F) and connect to the
Ination Port (C) by twisting to lock it in place
(see 2a below).
• Insert the tip of the nozzle into the item you are
inating – making sure that the nozzle ts into
the valve snugly to prevent air loss.
CAUTION
• This inator is not a toy - do not aim at yourself or others.
• Make sure that the Deation Port (D) is clear of obstructions when inating. The Deation Port is the
air intake and blocking it will cause poor performance and can damage the motor.
• Note: If you are not using the nozzles to inate, do not store them on the Deation Port (D) since
doing so will limit air intake and can affect performance and damage the motor.
• Press the On/Off Power Trigger (B) to lock the inator into the On position and begin inating.
• Note: Since most high volume inatables require very low air pressure - this inator does not have
an air pressure gauge – it is designed to inate to the correct “feel”.
• Press the On/Off Power – Trigger (B) to turn the inator Off when nished.
• Remove the nozzle and battery. Store all in a clean and dry environment (see page 10).
8
