THEORY GUIDE Equipment Description
10DEC05
TG4825-1
Page
12 of 120
Imaging • assembles the data from the screen and
changes it to digital format
• processes the image
Imaging Sequence
Logic and Control • processes commands from the operator
• controls the operation of all subsystems
• sends processed images to the network for
distribution
Logic and Control
Power Distribution • provides power for all subsystems
• includes an UNINTERRUPTIBLE POWER
SUPPLY (UPS)
• has an INTERLOCK SWITCH that actuates
when the FRONT DOOR is opened
Power Distribution
Error and Activity
Logs
• records logs of errors in the system
• records user actions
Logs
Subsystem Description See:
To Next Page
