www.kodak.com/go/aiosupport 36
KODAK ESP 5200 Series All-in-One Printer
5. Unlatch the used printhead by lifting the button in the center of the carriage.
6. Lift the used printhead out of the carriage.
7. Remove the new printhead from its bag.
CAUTION:
Do not touch the copper contacts on the printhead, as this may damage it.
To Next Page
