1 Printer Overview
This printer lets you print, copy, scan and fax pictures and documents. In addition,
this printer supports networking, letting you access the printer over a wireless
(Wi-Fi) or Ethernet network.
Components
1 Control panel 12 Front USB port
2 Automatic Document Feeder (ADF) paper
edge guides
13
Memory card slot
3ADF 14
Output tray extender with paper stop
4Power cord port 15
Scanner glass
5 USB port 16 Scanner lid
6 Line In phone port 17
Front paper-edge guides
7Ethernet port 18
Paper tray extender
8 Ext out phone port 19
Paper tray
9Duplexer 20
Left paper-edge guides
10
Access door
21 Photo paper tray
11 Printhead with ink cartridges installed
