Part Names
1 Buzzer
2 Wi-Fi indicator
3
Wi-Fi button / Direction button (lower) / Remote
control pairing (press and hold)
4 Lens B (235 Degree)
5 Lens status indicator B
6 Power button
7 Status indicator
8LCD
9 Bluetooth mark
10 Microphone
11
Video recording button /
Shooting button / OK button
12 Lens A (155 Degree)
13 Lens status indicator A
14
Menu button / Direction button (upper) / Mode
switching (press and hold)
15 NFC mark
16 Battery cover
17 Battery cover open Switch
18 Battery cover lock
19 Location hole
20 Tripod socket
5
4
7
6
3
2
1
13
12
10
11
14
15
20
19
18
17
16
8 9
