Block numbers up to 20 types (1 to 20) can be selected.
(12) Delete registered data by designating block number
Delete Alarm2 data registered with latitude/longitude.
Select Alarm2 block number to delete by using item (11) “Select Alarm2 block number”.
Move cursor [BLOCK CLEAR] => [CLEAR] then press [ENT] key.
(13) Select Alarm 2 detection method
Setting value : OFF, IN, OUT
• “IN” displays alarm indication and generates alarm sound when target enters into alarm setup area.
• “OUT” displays alarm indication and generates alarm sound when target leaves from alarm setup
area
• Off does not detect alarm.
This enables to use Alarm2 function to draw a simple figure by displaying the area of Alarm2 only.
(14) Setup Alarm 2 detection level
This item is to setup signal level for target detection in the alarm setup area.
Setting value is 1 to 7.
Small setting value responds to weak signal.
Large setting value responds to strong signal only.
Too low setting value responds to alarm even by noise.
Pay attention that too high value may not respond to weak target.
(15) Input/edit Alarm 2 data
LAT: Input latitude data.
LON: Input longitude data.
DIVIDE: OFF, ON
Up to 50 points can be input for 1 block. When divide is ON, input data is divided and displays
independently from the data to follow.
Area setting of Alarm2 requires to input at least 3 points. When dividing function is put on in
every 3 points, maximum 16 areas can be input and displayed within one block.
CLEAR：Clear Lat/Lon/Div data previously input.
SETUP : 1
LAT
LON
DIVIDE
CLEAR
LAT LON DIVIDE
1 ＿°＿＿．＿＿＿N ＿°＿＿．＿＿＿E
2
3
To Next Page
