Chapter 4 Menu operations MDC-2200/2500 Series
0093125002-05 4-46
4.11 I/O menu
Following setup items are provided in I/O Menu.
Input/output menu sets up NMEA data exchange setting for navigation devices.
Refer to Installation manual for detail operation of Input/output menu.
(1) Heading bearing
Set up input of heading bearing.
Set to “Off” when heading signal input is not input to use.
(2) Ship speed
Set up input of ship speed.
Set to “Off” when ship speed signal input is not input to use.
(3) COG/SOG
Set up input of signal for course on ground and speed on ground.
(4) Latitude/longitude
Set up input of latitude/longitude signals of own ship position.
(5) Ground stabilization setting
Select input signal for ground stabilization base.
(6) Output (J4, J5)
This is used to specify transmit interval of each sentence from J4 and J5 connector.
It is required when transmitting interval is specified for connecting device.
Setting items: GLL, HDT, RSD, OSD, TLL*, TTM, VDR, VHW, VTG
Setting value: 0.0 to 10.0 s
HDG
SPD
COG/SOG
LAT/LON
GND STAB MODE
OUTPUT (J4, J5)
BAUDRATE
INPUT
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
HDG (OFF / ON), Input setting, Manual setting, CORR, KGC-1 SET
SPD (OFF / ON), Input setting, Manual setting
AUTO, VTG, RMC, RMA
Input setting, Manual setting
AUTO / VDR / VBW / COG/SOG / MAN
Output data setting
J4, J5, J6 baud rate setting
Input sentence setting
