4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 100
APPLICATION SETUP — HAZARDOUS MOVEMENT MENU
ese parameters aect the Hazardous Movement fault, which detects such movements when the motor is requested
to rotate.
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Hazardous Direction
Response Time
Hazardous_Direction_
Response_Time
0x3E8D 0x00
0 – 10000 ms
0 – 10000
0 ms The (up/down) debounce timer on the Hazardous Movement fault,
Type 1.
Setting this value to 0 will disable this fault type.
Hazardous Throttle Response
Time
Hazardous_Throttle_Response_
Time
0x3E90 0x00
0 – 10000 ms
0 – 10000
0 ms The acceleration threshold for the Hazardous Movement fault,
Type 2.
Setting this value to 0 will disable this fault type.
Hazardous Speed Error
Hazardous_Speed_Error
0x3E8F 0x00
0 – 20000 rpm
0 – 20000
15000 rpm The speed threshold for the Hazardous Movement fault, Type 2.
Hazardous Accel
Hazardous_Accel
0x3E8E 0x00
0 – 10000 rpm/s
0 – 10000
5000 rpm/s The acceleration threshold for the Hazardous Movement fault,
Type 2.
APPLICATION SETUP — MOTOR BRAKING SUPERVISION MENU
ese parameters aect the Motor Braking Impaired fault, which detects when motor braking was impaired beyond
a safe threshold.
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Overall Cutback
OverallCutback
0x32D9 0X00
0.0 – 100.O %
0 – 4096
Read Only The accumulated controller cutback.
Motor Braking Impaired
Threshold
Motor_Braking_Impaired_
Threshold
0x32DA 0x00
0.0 – 100.O %
0 – 4096
0.0 % The threshold for OverallCutback below which a Motor Braking
Impaired fault will be generated after the specied time
(duration).
Motor Braking Impaired
Timer
Motor_Braking_Impaired_Timer
0x32D8 0x00
0 – 32767 ms
0 – 32767
Read Only This timer counts down when the OverallCutback is below
the parameterized threshold, if it reaches 0 a Motor Braking
Impaired fault will be generated.
Motor Braking Impaired Time
Motor_Braking_Impaired_Time
0x32DB 0x00
0 – 30000 ms
0 – 30000
64 ms The time the OverallCutback must be below the threshold for a
Motor Braking Impaired fault to be generated.
