Specifi cations
10
62 690 05 Rev. HKohlerEngines.com
TORQUE SPECIFICATIONS
3,5
ECV940 ECV980
Blower Housing and Sheet Metal
M6 Screw
New, Untapped Hole (casting)
Used, Tapped Hole (casting)
New, Extruded Hole (sheet metal)
Used, Extruded Hole (sheet metal)
Mounting Clip (valley baffl e)
10.7 N·m (95 in. lb.)
7.3 N·m (65 in. lb.)
2.5 N·m (22 in. lb.)
2.0 N·m (18 in. lb.)
2.5 N·m (22 in. lb.)
Intake Manifold and Air Cleaner
Intake Manifold Mounting Fastener (torque in 2 increments) fi rst to 16.9 N·m (150 in. lb.)
fi nally to 22.6 N·m (200 in. lb.)
Air Cleaner Elbow to Throttle Body Mounting Nut 7.9 N·m (70 in. lb.)
Air Cleaner Bracket Mounting Screw (into intake manifold) 11.3 N·m (100 in. lb.)
GCU Bracket to Intake Manifold & Air Cleaner Bracket 11.3 N·m (100 in. lb.)
Ground Lead to Air Cleaner Bracket 5.6 N·m (50 in. lb.)
HDAC to Electronic Throttle Body (ETB) Mounting Nut 8.3 N·m (73 in. lb.)
HDAC Bracket to HDAC Screw (ETB) 7.9 N·m (70 in. lb.)
Fuel Injector Cap Fastener 7.3 N·m (65 in. lb.)
Manifold Absolute Pressure (MAP) Sensor Fastener (Engines with
Separate MAP and Intake Air Temperature Sensors)
7.3 N·m (65 in. lb.)
Temperature/Manifold Absolute Pressure (TMAP) Sensor Fastener
(Engines with Combined Sensor)
7.3 N·m (65 in. lb.)
GENERAL SPECIFICATIONS
3,6
ECV940 ECV980
Bore 90 mm (3.54 in.)
Stroke 78.5 mm (3.1 in.)
Displacement 999 cc (61 cu. in.)
Oil Capacity (refi ll) 1.9-2.6 L (2.0-2.7 U.S. qt.)
Maximum Angle of Operation (@ full oil level)
4
25°
Model . . . . . . . . . . . . . . . . . . . . . ECV940
EFI Command Engine
Vertical Shaft
Numerical Designation
Specifi cation . . . . . . . . . . . . . . . ECV940-0001
Serial . . . . . . . . . . . . . . . . . . . . . 5023500328
Year Manufactured Code Factory Code
Code Year
50 2020
51 2021
52 2022
ENGINE IDENTIFICATION NUMBERS
Kohler engine identifi cation numbers (model, specifi cation and serial) should be referenced for effi cient repair,
ordering correct parts, and engine replacement.
3
Values are in Metric units. Values in parentheses are English equivalents.
4
Exceeding maximum angle of operation may cause engine damage from insuffi cient lubrication.
5
Lubricate threads with engine oil prior to assembly.
6
Any and all horsepower (hp) references by Kohler are Certifi ed Power Ratings and per SAE J1940 & J1995 hp
standards. Details on Certifi ed Power Ratings can be found at KohlerEngines.com.
