Kohler ECV940 User Manual

Specifi cations
1362 690 05 Rev. H
KohlerEngines.com
TORQUE SPECIFICATIONS
3,5
ECV940 ECV980
Oil Pan
Fastener 25.6 N·m (227 in. lb.)
Engine (Oil) Temperature Sensor 13.6 N·m (120 in. lb.)
Engine (Oil) Temperature Sensor Reducer Bushing 17.6 N·m (156 in. lb.)
Engine (Oil) Temperature Sensor Nut 2.3 N·m (20 in. lb.)
Oil Pickup Screen
Mounting Screw 11.3 N·m (100 in. lb.) into a new hole
7.7 N·m (68 in. lb.) into a used hole
Oil Pump
Mounting Screw 9.9 N·m (88 in. lb.)
Oil Sentry
TM
Pressure Switch 10.7 N·m (95 in. lb.)
Solenoid (starter)
Mounting Hardware 4.0-6.0 N·m (35-53 in. lb.)
Nut, Positive (+) Brush Lead 8.0-11.0 N·m (71-97 in. lb.)
Starter Assembly
Thru Bolt 5.6-9.0 N·m (49-79 in. lb.)
Mounting Screw 16 N·m (142 in. lb.)
Brush Holder Mounting Screw 2.5-3.3 N·m (22-29 in. lb.)
Stator
Mounting Screw 9.3 N·m (82 in. lb.)
Throttle Body
Mounting Stud (ETB) 3.7 N·m (32 in. lb.)
Throttle Control Bracket
Fastener 9.9 N·m (88 in. lb.)
Valve Cover
Aluminum Valve Cover Fastener
Into New Head Torque to 26 N·m (230 in. lb.) to ensure seal
seats in valve cover groove. Back off screw
to zero and then torque screw again to
18.1 N·m (160 in. lb.).
Into Used Head Torque to 16.4 N·m (145 in. lb.) to ensure seal
seats in valve cover groove. Back off screw
to zero and then torque screw again to
16.4 N·m (145 in. lb.).
Plastic Valve Cover Fastener 13.6 N·m (120 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
