Service and Repair Manual Repair
Driving gear
u Remove guiding rods.
u Remove locking device.
Installation
Fig. 112: Locking device
u Install locking device with screws (M16) to lock crankshaft.
Fig. 113: Lifting thread location
u Install lifting device on the lifting thread.
u Lift torsional vibration damper 1.
KD62V12 33525088601_7_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
103
