Driving gear
Information
Use lifting thread at the top to lift and align torsional vibration damper to flange.
u Position torsional vibration damper 1 using guiding rod.
u Install torsional vibration damper 1 with screws 2.
u Tighten screws 2 to torque.
u Position disk 3 and bolts 4.
u Tighten bolts 4 to torque.
u Remove locking device.
Specific values
Not applicable.
Tightening specifications
Fig. 114: Bolts sequence
104
