Fuel system
Removal
Fig. 133: Removing electrical contacts
u Remove electrical contacts from injector.
u Disconnect injector cable on both ends.
u Disconnect HT sensor on both ends if installed.
u Remove both adaptors from rocker arm housing.
Fig. 134: Removing high-pressure pipe
u Take off high-pressure pipe 5 from adaptor 9.
120
