Fuel system
Removal
u Remove flange joints 2, 3, 4, 5.
u Remove screws 6.
u Remove fuel filters 1.
Installation
u Install fuel filters 1 with screws 6.
u Tighten screws 6 to torque.
u Install flange joints 2, 3, 4, 5.
Specific values
Not applicable.
Tightening specifications
Fig. 147: Fuel filter screws
Reference
Key Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 201AA EN 1665 M10x1.5x30-8.8-FLZN - Yes 1 25 Nm
18 ft-lb
- -
Tab. 31: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
128
© 2021 by Kohler Co. All rights reserved.
KD62V12 33525088601_7_1 EN_US
2021-07
