Service and Repair Manual Repair
Exhaust gas system
Tightening specifications
Fig. 209: Exhaust pipe screws tightening sequence
Fig. 210: Exhaust pipe screws and plugs
Reference
Key Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 410AA DRW 10123168 M10x1.5x80-C3J MH No 1 52 Nm
38 ft-lb
- -
KD62V12 33525088601_7_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
185
