Exhaust gas system
Removal
u Loosen V-clamp 11.
u Remove screws 3 from outlet manifolds 2.
u Remove outlet manifolds 2.
u Remove screws 3 from outlet manifolds 9.
u Remove outlet manifolds 9.
u Remove screws 3 from outlet manifolds 10.
u Remove outlet manifolds 10.
u Remove screws 3 from outlet manifolds 13.
u Remove outlet manifolds 13.
Installation
u Install plug 6 with sealing ring 5 in outlet manifolds 2, 10.
u Install plug 8 with sealing ring 7 in outlet manifolds 2.
u Mount outlet manifolds 2, 10 together with seals 4, V-clamps 11 and compensator 12.
u Place outlet manifolds 2, 10 with seals 1 and screws 3.
u Mount outlet manifolds 9 on outlet manifolds 2, 10 with seals 4, V-clamps 11 and compen-
sator 12.
u Place outlet manifolds 9 with seals 1 and screws 3.
u Mount outlet manifolds 2, 13 on outlet manifolds 9 with seals 4, V-clamps 11 and compen-
sator 12.
u Mount outlet manifolds 2, 13 together with seals 4, V-clamps 11 and compensator 12.
u Place outlet manifolds 2, 13 with seals 1 and screws 3.
u Tighten plugs 6, 8, V-clamps 11 and screws 3 to torque.
Specific values
Not applicable.
