Service and Repair Manual Repair
Rocker arms
Fig. 75: Removing pushrods and valve bridges
u Remove valve bridges 3 and pushrods 2 from swing followers 1.
Installation
Information
Put matching cylinder in firing TDC position.
Fig. 76: Preparing inlet and exhaust shafts
u Inspect presence of plug in inlet shaft and exhaust shaft.
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
79
