Service and Repair Manual Repair
Exhaust gas system
3.8 Exhaust gas system
3.8.1 Admission pipes to turbocharger removal and installation
Previous tasks
q Disconnect admission connection of application set.
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
Special tools
Not applicable.
Consumables and equipment
– Rags
– Cleaner
Overview
Fig. 181: Task overview
1 Nut 5 Terminal flange
See next page for continuation of the image legend
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
159
