Maintenance Operation and Maintenance Manual
Fuel system
Ensure that:
q Preparatory maintenance activities are fullfilled. (For more information see: 5.5 Preparatory
maintenance activities, page 90) .
q A container with the required capacity is ready.
q Original KOHLER main fuel filters are available.
q A suitable drainage container is available.
q A fuel filter ribbon spanner is available.
Fuel filter removal
u Remove dust from sealing area.
u Open fuel filter 1 with filter ribbon spanner.
u Remove filter.
u Repeat procedure for all filters.
Fuel filter installation
u Remove dust from sealing area.
u Lubricate filter seal with engine oil.
u Screw fuel filter 1 in filter head 2 until it contacts base.
u Tighten filter by hand by 3/4 to 1 turn.
u Check for leaks and damages.
u Retighten if necessary.
5.9.3 Bleeding the fuel system
Refer to the generator set manual for more details.
5.9.4 Checking differential pressure — fuel prefilter — SL005
Refer to the generator set manual for more details.
118
© 2018 by Kohler Co. All rights reserved.
KD83V16 33521030601_0_1 EN_US
2018-07
