Kohler KD83V16

Transportation - Storage Operation and Maintenance Manual
Transport
Fig. 43: Example of waterproof packaging
3.3.3 Transport devices
Fig. 44: Examples of fixing the lifting devices on the engine
1 Engine 3 Lifting beam
2 Lifting hook 4 Lifting point
3.3.4 Transport conditions
Transport conditions should comply with the following minimum requirements:
Land transport:
In a freight wagon or a closed lorry.
